ELECTRICAL SYSTEM
L3301, L3901, L4701, WSM
9-S2
CHARGING SYSTEM
LIGHTING SYSTEM
Symptom Probable Cause Solution
Reference
Page
Charging Lamp Does
Not Light when Main
Switch Is Turned ON
Fuse blown Replace 9-S16
Wiring harness disconnected or improperly
connected
Repair or replace –
Alternator damaged Repair or replace 9-S35
Charging Lamp Does
Not Go OFF When
Engine Is Operating
Short circuit between alternator L terminal lead
and chassis
Repair or replace –
Alternator damaged Repair or replace 9-S35
Symptom Probable Cause Solution
Reference
Page
Head Light Does Not
Light
Fuse blown Replace 9-S16
Bulb blown Replace G-48, G-76
Wiring harness disconnected or improperly
connected
Repair or replace –
Combination switch damaged Replace 9-S36
Tail Light Does Not
Light
Fuse blown Replace 9-S16
Wiring harness disconnected or improperly
connected
Repair or replace –
Combination switch damaged Replace 9-S36
Hazard and Turn
Signal Light Does Not
Light
Fuse blown Replace 9-S16
Bulb blown Replace G-48, G-76
Wiring harness disconnected or improperly
connected
Repair or replace –
Hazard unit damaged Replace 9-S38
Combination Switch damaged Replace 9-S36
Hazard and Turn
Signal Light Does Not
Blink
Hazard unit damaged Replace 9-S38
Work Light Does Not
Light
Fuse blown Replace 9-S16
Bulb blown Replace G-48, G-76
Wiring harness disconnected or improperly
connected
Repair or replace –
KiSC issued 09, 2016 A
