2-3
2. Configuration
e. Select TCP/IP - Get IP Address and select Change
Settings.
f. Enter the IP address using the numeric keypad.
NOTE 1: Enter addresses in the format "xxx.xxx.xxx.xxx"
where xxx should be a numeric value in the range from 0 to
255. However, 224 or 225.xxx.xxx.xxx and 127.xxx.xxx.xxx
cannot be used.
NOTE 2: When you make an entry mistake, press the C
(Clear) button and enter again.
NOTE 3: When you would like to move to the next value
without entering all 3 digits, select Next.
g. Select Save.
h. Configure TCP/IP - Subnet Mask and TCP/IP - Gateway
Address as shown above.
NOTE 1: Enter addresses in the format "xxx.xxx.xxx.xxx"
where xxx should be a numeric value in the range from 0 to
255. However, 224 or 225.xxx.xxx.xxx and 127.xxx.xxx.xxx
cannot be used.
NOTE 2: Specify the subnet mask by a combination of the
numbers 0, 128, 192, 224, 248, 252, and 255. However, you
cannot use 0 between non-zero values.
NOTE 3: If you do not wish to set the gateway address, enter
"0.0.0.0."
4. Select Close repeatedly until the System Settings screen is
displayed.
5. Select Exit.
6. After the machine is restarted, print out the Printer Settings
List to confirm that the LPD port is enabled.
Configure the LPD as necessary. Refer to “LPD” on page 3-15 for
the for the LPD configuration. Also if using Port 9100, configure as
necessary. Refer to “Port 9100” on page 3-19 for the Port 9100
configuration.
