Xerox 4595 Copier/Printer System Administration Guide
3-16
3. Using CentreWare Internet Services
SNMP
This section describes the settings for SNMP.
NOTE: When using the CentreWare software to manage the
machine by remote control, enable the SNMP port.
1. Start a web browser.
2. Type the IP address or the Internet address for the machine in
the address bar on the browser, and press the Enter key.
• Example of the IP address entry:
http://192.168.1.1/
• Example of the Internet address entry:
http://xxx.yyyy.zz.vvv/
NOTE: When specifying a port number, add ":" and a port
number to the end of the Internet address.
3. Click the Properties tab.
4. Click + on the left of Protocol Settings to display the items in
the folder.
5. Click SNMP.
6. When changing the community name, set all the Community
Name (Read only), Community Name (Read/Write), and
Community Name (Trap Notification).
NOTE: Normally, do not change the settings.
