Xerox 4595 - Page 66

Xerox 4595 Copier/Printer System Administration Guide
3-18
3. Using CentreWare Internet Services
3. Click the Properties tab.
4. Click + on the left of Protocol Settings to display the items in
the folder.
5. Click IPP.
6. Set the Additional Port Number.
7. Select the Enable check box to enable the TBCP Filter.
8. Select the Enable check box to enable Administration Mode.
9. Select the Enable check box to enable DNS.
10.Set the Connection Time-Out.
11.Reflect the values as the machine's setting values.
a. Click the Apply New Settings. A screen to enter the user
name and password will be displayed.
b. Enter the System Administrator UserID and password into
User Name and Password, and then click OK.
NOTE:The default User ID value is 11111 and password is
x-admin.
c. The right frame on the web browser will change to the
machine reboot display.
d. Click Reboot.The machine will reboot and the setting
value will be reflected.
