Product Overview
2
Note • The C-Finisher and the C-Finisher with Booklet Maker are optional. In some sections of this
guide, they are referred to as "finisher".
îš„Tandem Tray Module + B-Finisher
Note • The B-Finisher is optional. In some sections of this guide, it is referred to as "finisher".
21 Document feeder glass Scans documents loaded in the document feeder.
22 Toner cartridge Contains toner (image forming powder).
23 Drum cartridge Contains a photo conductor to transfer toner.
No. Component Function
24 B-Finisher (optional) Allows you to staple printed or copied documents.
25 Finisher top cover button Pressed to open the upper cover of the finisher when clearing paper
jams.
26 Finisher tray Stapled documents are delivered.
27 Front cover Opened to clear staple jams, or replace staples.
28 Staple cartridge Contains staples.
29 Stand Connects the machine and the finisher.
30 Finisher transport cover Opened to clear paper jams.
31 Tray 3 - 4 (optional) Accommodates paper.
No. Component Function
30
29
28
27
25
24
26
31
To Next Page
