Job Editor 81
3. To view the thumbnails side by side, resize the thumbnail pane by dragging the
bar that divides the panes in the tab.
4. Double-click the thumbnail of the page that you want to view.
The page is displayed in the right pane.
The Imposed Sheets Tab
The Imposed Sheets tab is available only for imposed RTP jobs. This tab enables you
to view the imposed sheets and check your imposition parameters. You cannot edit
the job on this tab.
To display a page of an Imposed job:
1. Click the Thumbnails or Booklets tab.
2. Select the desired thumbnail or page.
3. Click the Imposed sheets tab.
The selected page of the imposed job appears.
Note: The Imposed Sheets tab is available only if you have the Pro
configuration.
Notes:
• In VI jobs, the booklet number appears in instead of the sheet number—for
example,
Booklet 1, Page 15.
• In duplex jobs, each sheet is displayed twice, once for side A, and once for
side B. For example,
Sheet 1, Side A.
