Troubleshooting
246 WorkCentre 6605 Color Multifunction Printer
User Guide
Clearing Paper Jams from the Fuser Area
To resolve the error displayed on the control panel you must clear all paper from the paper path.
1. Push down on the rear door release and pull open the door.
2. Lift the levers as shown.
3. To lift the top paper guide on the top of the fuser, use the tabs to pull it up and out.
To Next Page
