Installation and Setup
86 WorkCentre 6605 Color Multifunction Printer
User Guide
Configuring Kerberos Server Settings
1. At your computer, open a Web browser, type the IP address of the printer in the address field,
then press Enter or Return.
2. In CentreWare Internet Services, click Properties.
3. In the Properties pane, to expand the menu, click the plus (+) symbol next to the Security folder.
4. Click Kerberos Server.
5. Next to IP Address/Host Name and Port, enter the IP address or the network host name for the
Kerberos server, then enter the port number.
6. Next to Domain Name, enter the domain name of your authentication server.
7. Next to Login Name, enter the user name for logging in to the server.
8. Next to Password, enter and re-enter the password for the server.
9. Click Save Changes.
Configuring LDAP Authentication
1. At your computer, open a Web browser, type the IP address of the printer in the address field,
then press Enter or Return.
2. In CentreWare Internet Services, click Properties.
3. In the Properties pane, to expand the menu, click the plus (+) symbol next to the Security folder.
4. Click LDAP Authentication.
5. To use a text string to add to the user name, next to Use Added Text String, select Enable.
6. Next to Text String Added to User Name, enter the text string to add to the user name for
authentication.
7. Click Save Changes.
Configuring the Host Access List
The host access list controls access to the printer over LPR or Port 9100. You can enter up to five IP
address/mask combinations, and then select to reject, accept, or turn off the filtering for each IP
address. You can enter a specific IP address and address mask, or you can enter a range of IP
addresses and address masks. If no IP address and address mask is entered in the host access list,
there are no limitations on printer access.
You can allow printing from one specific IP address only. The access list would look like the following
table:
Access List IP Address Address Mask Operation
1 192.168.200.10 255.255.255.255 Accept
