Xilinx MicroBlaze Reference Guide

MicroBlaze Processor Reference Guide 197
UG984 (v2018.2) June 21, 2018 www.xilinx.com
Chapter 5: MicroBlaze Instruction Set Architecture
add
Arithmetic Add
add rD, rA, rB Add
addc rD, rA, rB Add with Carry
addk rD, rA, rB Add and Keep Carry
addkc rD, rA, rB Add with Carry and Keep Carry
0 0 0 K C 0 rD rA rB 0 0 0 0 0 0 0 0 0 0 0
0 6 11 16 21
31
Description
The sum of the contents of registers rA and rB, is placed into register rD.
Bit 3 of the instruction (labeled as K in the figure) is set to one for the mnemonic addk. Bit 4 of the
instruction (labeled as C in the figure) is set to one for the mnemonic addc. Both bits are set to one
for the mnemonic addkc.
When an add instruction has bit 3 set (addk, addkc), the carry flag will Keep its previous value
regardless of the outcome of the execution of the instruction. If bit 3 is cleared (add, addc), then the
carry flag will be affected by the execution of the instruction.
When bit 4 of the instruction is set to one (addc, addkc), the content of the carry flag (MSR[C]) affects
the execution of the instruction. When bit 4 is cleared (add, addk), the content of the carry flag does
not affect the execution of the instruction (providing a normal addition).
Pseudocode
if C = 0 then
(rD) ← (rA) + (rB)
else
(rD)
← (rA) + (rB) + MSR[C]
if K = 0 then
MSR[C]
← CarryOut
Registers Altered
•rD
•MSR[C]
Latency
1 cycle
Notes
The C bit in the instruction opcode is not the same as the carry bit in the MSR.
The “add r0, r0, r0” (= 0x00000000) instruction is never used by the compiler and usually indicates
uninitialized memory. If you are using illegal instruction exceptions you can trap these instructions by
setting the MicroBlaze parameter C_OPCODE_0x0_ILLEGAL=1.
Send Feedback

Xilinx MicroBlaze Specifications

General

Architecture	32-bit RISC
Cache	Configurable Instruction and Data Cache
Category	Soft Processor Core
Data Width	32-bit
Memory Management Unit (MMU)	Optional
Floating Point Unit (FPU)	Optional
Interrupt Controller	Configurable
Memory Management	Optional MMU
Configurability	Highly Configurable
Pipeline Stages	3-stage
FPGA Integration	Xilinx FPGAs
Bus Interface	PLB
Debug Interface	JTAG
Typical Clock Speed	Varies depending on FPGA and configuration (e.g., 100-400+ MHz)
Implementation	Soft core (synthesized logic)
Maximum Performance	Varies with FPGA and configuration
Debug Support	Integrated Debug Module
