MicroBlaze Processor Reference Guide 207
UG984 (v2018.2) June 21, 2018 www.xilinx.com
Chapter 5: MicroBlaze Instruction Set Architecture
bgt
Branch if Greater Than
bgt
rA, rB
Branch if Greater Than
bgtd
rA, rB
Branch if Greater Than with Delay
1 0 0 1 1 1 D 0 1 0 0 rA rB 0 0 0 0 0 0 0 0 0 0 0
0 6 11 16 21
31
Description
Branch if rA is greater than 0, to the instruction located in the offset value of rB. The target of the
branch will be the instruction at address PC + rB.
The mnemonic bgtd will set the D bit. The D bit determines whether there is a branch delay slot or not.
If the D bit is set, it means that there is a delay slot and the instruction following the branch (that is,
in the branch delay slot) is allowed to complete execution before executing the target instruction. If
the D bit is not set, it means that there is no delay slot, so the instruction to be executed after the
branch is the target instruction.
Pseudocode
If rA > 0 then
PC ← PC + rB
else
PC
← PC + 4
if D = 1 then
allow following instruction to complete execution
Registers Altered
•PC
Latency
• 1 cycle (if branch is not taken)
• 2 cycles (if branch is taken and the D bit is set)
• 3 cycles (if branch is taken and the D bit is not set)
Note
A delay slot must not be used by the following: imm, branch, or break instructions. Interrupts and
external hardware breaks are deferred until after the delay slot branch has been completed.
