Chapter 2: MicroBlaze Architecture
Table 2-9: Machine Status Register (MSR)
Bits Name Description Reset Value
0 CC Arithmetic Carry Copy
Copy of the Arithmetic Carry (bit 29). CC is always the same as bit C.
0
1:16 Reserved
17 VMS Virtual Protected Mode Save
Only available when configured with an MMU
(if C_USE_MMU > 1 and C_AREA_OPTIMIZED = 0 or 2)
Read/Write
0
18 VM Virtual Protected Mode
0 = MMU address translation and access protection disabled, with
C_USE_MMU = 3 (Virtual). Access protection disabled with
C_USE_MMU = 2 (Protection)
1 = MMU address translation and access protection enabled, with
C_USE_MMU = 3 (Virtual). Access protection enabled, with
C_USE_MMU = 2 (Protection).
Only available when configured with an MMU
(if C_USE_MMU > 1 and C_AREA_OPTIMIZED = 0 or 2)
Read/Write
0
19 UMS User Mode Save
Only available when configured with an MMU
(if C_USE_MMU > 0 and C_AREA_OPTIMIZED = 0 or 2)
Read/Write
0
20 UM User Mode
0 = Privileged Mode, all instructions are allowed
1 = User Mode, certain instructions are not allowed
Only available when configured with an MMU
(if C_USE_MMU > 0 and C_AREA_OPTIMIZED = 0 or 2)
Read/Write
0
21 PVR Processor Version Register exists
0 = No Processor Version Register
1 = Processor Version Register exists
Read only
Based on
parameter
C_PVR
22 EIP Exception In Progress
0 = No hardware exception in progress
1 = Hardware exception in progress
Only available if configured with exception support
(
C_*_EXCEPTION or C_USE_MMU > 0)
Read/Write
0
