Xilinx Vivado MIPI CSI-2 User Manual

MIPI CSI-2 RX Subsystem v4.0 18
PG232 July 02, 2019 www.xilinx.com
Chapter 2: Product Specification
video_out_tready Input Slave ready to accept the data
video_out_tuser[n-1:0] Output
n is based on TUSER width selected in the Vivado IDE
95-80 CRC
(3)
79-72 ECC
71-70 Reserved
69-64 Data Type
63-48 Word Count
47-32 Line Number
31-16 Frame Number
15-2 Reserved
1 Packet Error
0Start of Frame
(2)
video_out_tlast Output End of line
video_out_tdata[n-1:0] Output
Data
n is based on Data type and number of pixels selected in the
Vivado IDE (see video_out Port Width).
video_out_tdest[9:0] Output
9-4 Data Type
3-0 Virtual Channel Identifier (VC)
AXI4-Stream Interface when Embedded Non-image Interface is Selected
emb_nonimg_tdata[n-1:0] output
Data
n is based on Data type selected in the Vivado IDE (see
Table 1-1).
emb_nonimg_tdest[3:0] Output
Specifies the Virtual Channel Identifier (VC) value of the
embedded non-image packet
emb_nonimg_tkeep[n/8-1:0] Output Specifies valid bytes
emb_nonimg_tlast Output End of line
emb_nonimg_tready Input Slave ready to accept data
Table 2-5: Port Descriptions (Cont’d)
Signal Name Direction Description
