Xilinx ZCU106 User Manual

ZCU106 Board User Guide 31
UG1244 (v1.0) March 28, 2018 www.xilinx.com
Chapter 3: Board Component Descriptions
W29 DDR4_SODIMM_DQ45 190 DQ45
W28 DDR4_SODIMM_DQ46 203 DQ46
V27 DDR4_SODIMM_DQ47 204 DQ47
AA32 DDR4_SODIMM_DQ48 216 DQ48
AA33 DDR4_SODIMM_DQ49 215 DQ49
AA34 DDR4_SODIMM_DQ50 228 DQ50
AE34 DDR4_SODIMM_DQ51 229 DQ51
AD34 DDR4_SODIMM_DQ52 211 DQ52
AB31 DDR4_SODIMM_DQ53 212 DQ53
AC34 DDR4_SODIMM_DQ54 224 DQ54
AC33 DDR4_SODIMM_DQ55 225 DQ55
AA30 DDR4_SODIMM_DQ56 237 DQ56
Y30 DDR4_SODIMM_DQ57 236 DQ57
AA31 DDR4_SODIMM_DQ58 249 DQ58
W30 DDR4_SODIMM_DQ59 250 DQ59
Y33 DDR4_SODIMM_DQ60 232 DQ60
W33 DDR4_SODIMM_DQ61 233 DQ61
W34 DDR4_SODIMM_DQ62 245 DQ62
Y34 DDR4_SODIMM_DQ63 246 DQ63
AF32 DDR4_SODIMM_CB0 92 CB0/NC
AE32 DDR4_SODIMM_CB1 91 CB1/NC
AH33 DDR4_SODIMM_CB2 101 CB2/NC
AE33 DDR4_SODIMM_CB3 105 CB3/NC
AF33 DDR4_SODIMM_CB4 88 CB4/NC
AH34 DDR4_SODIMM_CB5 87 CB5/NC
AJ34 DDR4_SODIMM_CB6 100 CB6/NC
AK34 DDR4_SODIMM_CB7 104 CB7/NC
AN24 DDR4_SODIMM_DM0_B 12 DM0_N/DBI0_N
AM29 DDR4_SODIMM_DM1_B 33 DM1_N/DBI1_N
AH24 DDR4_SODIMM_DM2_B 54 DM2_N/DBI2_N
AJ29 DDR4_SODIMM_DM3_B 75 DM3_N/DBI3_N
AD29 DDR4_SODIMM_DM4_B 178 DM4_N/DBI4_N
Y29 DDR4_SODIMM_DM5_B 199 DM5_N/DBI5_N
AC32 DDR4_SODIMM_DM6_B 220 DM6_N/DBI6_N
Table 3-3: DDR4 SODIMM Socket J1 Connections to FPGA PS DDR Bank 504 (Cont’d)
XCZU7EV (U1) Pin Net Name
DDR4 SODIMM Memory J1
Pin Number Pin Name
Send Feedback
