ZCU106 Board User Guide 32
UG1244 (v1.0) March 28, 2018 www.xilinx.com
Chapter 3: Board Component Descriptions
Y32 DDR4_SODIMM_DM7_B 241 DM7_N/DBI7_N
AF34 DDR4_SODIMM_DM8_B 96 DM8_N/DBI8_N/NC
AN26 DDR4_SODIMM_DQS0_T 13 DQS0_T
AN27 DDR4_SODIMM_DQS0_C 11 DQS0_C
AN29 DDR4_SODIMM_DQS1_T 34 DQS1_T
AP30 DDR4_SODIMM_DQS1_C 32 DQS1_C
AH26 DDR4_SODIMM_DQS2_T 55 DQS2_T
AJ26 DDR4_SODIMM_DQS2_C 53 DQS2_C
AK28 DDR4_SODIMM_DQS3_T 76 DQS3_T
AK29 DDR4_SODIMM_DQS3_C 74 DQS3_C
AD30 DDR4_SODIMM_DQS4_T 179 DQS4_T
AD31 DDR4_SODIMM_DQS4_C 177 DQS4_C
Y27 DDR4_SODIMM_DQS5_T 200 DQS5_T
Y28 DDR4_SODIMM_DQS5_C 198 DQS5_C
AB33 DDR4_SODIMM_DQS6_T 221 DQS6_T
AB34 DDR4_SODIMM_DQS6_C 219 DQS6_C
W31 DDR4_SODIMM_DQS7_T 242 DQS7_T
W32 DDR4_SODIMM_DQS7_C 240 DQS7_C
AG33 DDR4_SODIMM_DQS8_T 97 DQS8_T
AG34 DDR4_SODIMM_DQS8_C 95 DQS8_C
AL31 DDR4_SODIMM_CK0_C 139 CK0_C
AN32 DDR4_SODIMM_CK0_T 137 CK0_T
AL30 DDR4_SODIMM_CK1_C 140 CK1_C/NF
AL32 DDR4_SODIMM_CK1_T 138 CK1_T/NF
AN33 DDR4_SODIMM_CKE0 109 CKE0
AH32 DDR4_SODIMM_CKE1 110 CKE1
AP32 DDR4_SODIMM_ODT0 155 ODT0
AJ32 DDR4_SODIMM_ODT1 161 ODT1
AF28 DDR4_SODIMM_RAS_B 152 RAS_N/A16
AG28 DDR4_SODIMM_CAS_B 156 CAS_N/A15
AG29 DDR4_SODIMM_WE_B 151 WE_N/A14
AE25 DDR4_SODIMM_ACT_B 114 ACT_N
AB26 DDR4_SODIMM_ALERT_B 116 ALERT_N
AA26 DDR4_SODIMM_PARITY 143 PARITY
Table 3-3: DDR4 SODIMM Socket J1 Connections to FPGA PS DDR Bank 504 (Cont’d)
XCZU7EV (U1) Pin Net Name
DDR4 SODIMM Memory J1
Pin Number Pin Name
Send Feedback
