Xilinx ZCU106 User Manual

ZCU106 Board User Guide 34
UG1244 (v1.0) March 28, 2018 www.xilinx.com
Chapter 3: Board Component Descriptions
AD17 DDR4_DQ15 POD12_DCI D7 DQU7 U101
AH14 DDR4_DQS0_T DIFF_POD12_DCI G3 DQSL_T U101
AJ14 DDR4_DQS0_C DIFF_POD12_DCI F3 DQSL_C U101
AA16 DDR4_DQS1_T DIFF_POD12_DCI B7 DQSU_T U101
AA15 DDR4_DQS1_C DIFF_POD12_DCI A7 DQSU_C U101
AH18 DDR4_DM0 POD12_DCI E7 DML_B/DBIL_B U101
AD15 DDR4_DM1 POD12_DCI E2 DMU_B/DBIU_B U101
AJ16 DDR4_DQ16 POD12_DCI G2 DQL0 U99
AJ17 DDR4_DQ17 POD12_DCI F7 DQL1 U99
AL15 DDR4_DQ18 POD12_DCI H3 DQL2 U99
AK17 DDR4_DQ19 POD12_DCI H7 DQL3 U99
AJ15 DDR4_DQ20 POD12_DCI H2 DQL4 U99
AK18 DDR4_DQ21 POD12_DCI H8 DQL5 U99
AL16 DDR4_DQ22 POD12_DCI J3 DQL6 U99
AL18 DDR4_DQ23 POD12_DCI J7 DQL7 U99
AP13 DDR4_DQ24 POD12_DCI A3 DQU0 U99
AP16 DDR4_DQ25 POD12_DCI B8 DQU1 U99
AP15 DDR4_DQ26 POD12_DCI C3 DQU2 U99
AN16 DDR4_DQ27 POD12_DCI C7 DQU3 U99
AN13 DDR4_DQ28 POD12_DCI C2 DQU4 U99
AM18 DDR4_DQ29 POD12_DCI C8 DQU5 U99
AN17 DDR4_DQ30 POD12_DCI D3 DQU6 U99
AN18 DDR4_DQ31 POD12_DCI D7 DQU7 U99
AK15 DDR4_DQS2_T DIFF_POD12_DCI G3 DQSL_T U99
AK14 DDR4_DQS2_C DIFF_POD12_DCI F3 DQSL_C U99
AM14 DDR4_DQS3_T DIFF_POD12_DCI B7 DQSU_T U99
AN14 DDR4_DQS3_C DIFF_POD12_DCI A7 DQSU_C U99
AM16 DDR4_DM2 POD12_DCI E7 DML_B/DBIL_B U99
AP18 DDR4_DM3 POD12_DCI E2 DMU_B/DBIU_B U99
AB19 DDR4_DQ32 POD12_DCI G2 DQL0 U100
AD19 DDR4_DQ33 POD12_DCI F7 DQL1 U100
AC18 DDR4_DQ34 POD12_DCI H3 DQL2 U100
AC19 DDR4_DQ35 POD12_DCI H7 DQL3 U100
AA20 DDR4_DQ36 POD12_DCI H2 DQL4 U100
Table 3-4: DDR4 Component Memory Connection to the XCZU7EV MPSoC (Cont’d)
XCZU7EV
(U1) Pin
Net Name I/O Standard
DDR4 Component Memory
Pin # Pin Name Ref. Des.
