ZCU106 Board User Guide 35
UG1244 (v1.0) March 28, 2018 www.xilinx.com
Chapter 3: Board Component Descriptions
AE20 DDR4_DQ37 POD12_DCI H8 DQL5 U100
AA19 DDR4_DQ38 POD12_DCI J3 DQL6 U100
AD20 DDR4_DQ39 POD12_DCI J7 DQL7 U100
AF22 DDR4_DQ40 POD12_DCI A3 DQU0 U100
AH21 DDR4_DQ41 POD12_DCI B8 DQU1 U100
AG19 DDR4_DQ42 POD12_DCI C3 DQU2 U100
AG21 DDR4_DQ43 POD12_DCI C7 DQU3 U100
AE24 DDR4_DQ44 POD12_DCI C2 DQU4 U100
AG20 DDR4_DQ45 POD12_DCI C8 DQU5 U100
AE23 DDR4_DQ46 POD12_DCI D3 DQU6 U100
AF21 DDR4_DQ47 POD12_DCI D7 DQU7 U100
AA18 DDR4_DQS4_T DIFF_POD12_DCI G3 DQSL_T U100
AB18 DDR4_DQS4_C DIFF_POD12_DCI F3 DQSL_C U100
AF23 DDR4_DQS5_T DIFF_POD12_DCI B7 DQSU_T U100
AG23 DDR4_DQS5_C DIFF_POD12_DCI A7 DQSU_C U100
AE18 DDR4_DM4 POD12_DCI E7 DML_B/DBIL_B U100
AH22 DDR4_DM5 POD12_DCI E2 DMU_B/DBIU_B U100
AL22 DDR4_DQ48 POD12_DCI G2 DQL0 U100
AJ22 DDR4_DQ49 POD12_DCI F7 DQL1 U2
AL23 DDR4_DQ50 POD12_DCI H3 DQL2 U2
AJ21 DDR4_DQ51 POD12_DCI H7 DQL3 U2
AK20 DDR4_DQ52 POD12_DCI H2 DQL4 U2
AJ19 DDR4_DQ53 POD12_DCI H8 DQL5 U2
AK19 DDR4_DQ54 POD12_DCI J3 DQL6 U2
AJ20 DDR4_DQ55 POD12_DCI J7 DQL7 U2
AP22 DDR4_DQ56 POD12_DCI A3 DQU0 U2
AN22 DDR4_DQ57 POD12_DCI B8 DQU1 U2
AP21 DDR4_DQ58 POD12_DCI C3 DQU2 U2
AP23 DDR4_DQ59 POD12_DCI C7 DQU3 U2
AM19 DDR4_DQ60 POD12_DCI C2 DQU4 U2
AM23 DDR4_DQ61 POD12_DCI C8 DQU5 U2
AN19 DDR4_DQ62 POD12_DCI D3 DQU6 U2
AN23 DDR4_DQ63 POD12_DCI D7 DQU7 U2
AK22 DDR4_DQS6_T DIFF_POD12_DCI G3 DQSL_T U2
Table 3-4: DDR4 Component Memory Connection to the XCZU7EV MPSoC (Cont’d)
XCZU7EV
(U1) Pin
Net Name I/O Standard
DDR4 Component Memory
Pin # Pin Name Ref. Des.
