ZCU106 Board User Guide 36
UG1244 (v1.0) March 28, 2018 www.xilinx.com
Chapter 3: Board Component Descriptions
AK23 DDR4_DQS6_C DIFF_POD12_DCI F3 DQSL_C U2
AM21 DDR4_DQS7_T DIFF_POD12_DCI B7 DQSU_T U2
AN21 DDR4_DQS7_C DIFF_POD12_DCI A7 DQSU_C U2
AL20 DDR4_DM6 POD12_DCI E7 DML_B/DBIL_B U2
AP19 DDR4_DM7 POD12_DCI E2 DMU_B/DBIU_B U2
AK9 DDR4_A0 SSTL12_DCI P3 A0 U2,U99-U101
AG11 DDR4_A1 SSTL12_DCI P7 A1 U2,U99-U101
AJ10 DDR4_A2 SSTL12_DCI R3 A2 U2,U99-U101
AL8 DDR4_A3 SSTL12_DCI N7 A3 U2,U99-U101
AK10 DDR4_A4 SSTL12_DCI N3 A4 U2,U99-U101
AH8 DDR4_A5 SSTL12_DCI P8 A5 U2,U99-U101
AJ9 DDR4_A6 SSTL12_DCI P2 A6 U2,U99-U101
AG8 DDR4_A7 SSTL12_DCI R8 A7 U2,U99-U101
AH9 DDR4_A8 SSTL12_DCI R2 A8 U2,U99-U101
AG10 DDR4_A9 SSTL12_DCI R7 A9 U2,U99-U101
AH13 DDR4_A10 SSTL12_DCI M3 A10/AP U2,U99-U101
AG9 DDR4_A11 SSTL12_DCI T2 A11 U2,U99-U101
AM13 DDR4_A12 SSTL12_DCI M7 A12/BC_B U2,U99-U101
AF8 DDR4_A13 SSTL12_DCI T8 A13 U2,U99-U101
AK8 DDR4_BA0 SSTL12_DCI N2 BA0 U2,U99-U101
AL12 DDR4_BA1 SSTL12_DCI N8 BA1 U2,U99-U101
AE14 DDR4_BG0 SSTL12_DCI M2 BG0 U2,U99-U101
AC12 DDR4_A14_WE_B SSTL12_DCI L2 WE_B/A14 U2,U99-U101
AF11 DDR4_A16_RAS_B SSTL12_DCI L8 RAS_B/A16 U2,U99-U101
AE12 DDR4_A15_CAS_B SSTL12_DCI M8 CAS_B_A15 U2,U99-U101
AH11 DDR4_CK_T DIFF_SSTL12_DCI K7 CK_T U2,U99-U101
AJ11 DDR4_CK_C DIFF_SSTL12_DCI K8 CK_C U2,U99-U101
AB13 DDR4_CKE SSTL12_DCI K2 CKE U2,U99-U101
AD14 DDR4_ACT_B SSTL12_DCI L3 ACT_B U2,U99-U101
R156 P/D DDR4_TEN SSTL12_DCI N9 TEN U2,U99-U101
R499 P/U DDR4_ALERT_B SSTL12_DCI P9 ALERT_B U2,U99-U101
AC13 DDR4_PAR SSTL12_DCI T3 PAR U2,U99-U101
AF12 DDR4_RESET_B LVCMOS12 P1 RESET_B U2,U99-U101
Table 3-4: DDR4 Component Memory Connection to the XCZU7EV MPSoC (Cont’d)
XCZU7EV
(U1) Pin
Net Name I/O Standard
DDR4 Component Memory
Pin # Pin Name Ref. Des.
