Xilinx ZCU106

ZCU106 Board User Guide 44
UG1244 (v1.0) March 28, 2018 www.xilinx.com
Chapter 3: Board Component Descriptions
Table 3-10 lists the SD card interface connections to the XCZU7EV MPSoC.
15 B1 DATA3_H
16 E1 DATA1_H
17 E3 DIR_1_3
18 A1 DATA2_H
19 E5 DATA1_SD
20 D5 DATA0_SD
21 C5 CLK_SD
22 D4 CMD_SD
23 B5 DATA3_SD
24 A5 DATA2_SD
25 C2 ENABLE
Table 3-10: SD Interface Connections to the XCZU7EV MPSoC
XCZU7EV
(U1) Pin
Net Name
U133 IP4856CX25
Adapter
Pin # Pin Name
D30 MIO39_SDIO_SEL 14 SEL
D31 MIO40_SDIO_DIR_CMD 12 DIR_CMD
D32 MIO41_SDIO_DIR_DAT0 9 DIR_0
D34 MIO42_SDIO_DIR_DAT1_3 17 DIR_1_3
E34 MIO46_SDIO_DAT0 13 DATA0_H
F30 MIO47_SDIO_DAT1 16 DATA1_H
F31 MIO48_SDIO_DAT2 18 DATA2_H
F32 MIO49_SDIO_DAT3 15 DATA3_H
F33 MIO50_SDIO_CMD 4 CMD_H
F34 MIO51_SDIO_CLK 1 CLK_IN
E32 MIO44_SDIO_PROTECT 6 WP
E33 MIO45_SDIO_DETECT 3 CD
Table 3-9: U133 IP4856CX25 Adapter Pin-Out (Cont’d)
Aries Adapter Pin
Number
IP4856CX25 U133
Pin Number
IP4856CX25 U133 Pin Name
