MOTIF XS8
MOTIF XS8
MOTIF XS8
MOTIF XS8 OVERALL CIRCUIT DIAGRAM 9/11 (MLAN 2/2)
<Page 10>
MLAN 2/2
Note : See parts list for details of circuit board component parts.
注： シートの部品詳細はパーツリストをご参照ください。
D-FF
D-FF
D-FF
AND
AND
AND
BUFFER
TRANSCEIVER
TRANSCEIVER
TRANSCEIVER
TRANSCEIVER
TRANSCEIVER
SCR16
(Gate Array)
SCR16
(Gate Array)
AND
AND
AND
AND
DICE2
DICE2
REGULATOR +1.8V
< P.9 MLAN1/2 D-2>
< P.9 MLAN1/2 C-2>
< P.9 MLAN1/2 C-3>
< P.9 MLAN1/2 C-3>
< P.9 MLAN1/2 C-2>
< P.9 MLAN1/2 C-2>
< P.9 MLAN1/2 C-2>
< P.9 MLAN1/2 D-2>
< P.9 MLAN1/2 D-5>
< P.9 MLAN1/2 D-5>
< P.9 MLAN1/2 D-5>
< P.9 MLAN1/2 D-5>
< P.9 MLAN1/2 O-10>
< P.9 MLAN1/2 O-10>
< P.9 MLAN1/2 O-10>
< P.9 MLAN1/2 O-10>
RB160M-30
(
WC549600
)
DIODE
MLAN: D100
1: ANODE
2: CATHODE
1
2
R1114N181A-TR (X7764A00)
REGULATOR +1.8V
MLAN: IC127
1: VDD
2: GND
3: CE or CE
4: NC
5: V
OUT
1
2
3
4
5
to JKAN-ML - CN402 <Page 11 M-3>
Not installed
Not installed
Not installedNot installed
Not installed
Not installed
28CC1-2001007347-0020 2
: Ceramic Capacitor (chip)
: Mylar Capacitor (chip)（チップマイラーコンデンサー）
（チップセラミックコンデンサー）
: Metal Film Resistor (chip)（チップ金属被膜抵抗）

Yamaha Motif XS Series Specifications

General

Type	Workstation Synthesizer
Sound Engine	AWM2 with Expanded Articulation
Polyphony	128 notes
Wave ROM	355MB (when converted to 16-bit linear format)
Arpeggiator	6, 000 types
Effects	Reverb, chorus, part EQ
Sequencer	16-track sequencer, 130, 000 notes
Display	320 x 240 dot backlit LCD
Connectivity	USB, MIDI In/Out/Thru
Storage	USB storage device support
Keyboard	88-key (Motif XS8), 76-key (Motif XS7), 61-key (Motif XS6)
Number of Voices	1, 024 normal voices + 64 drum kits
