Pump Quick Setup Menu Depending on A1-06 Setting
The following table shows which parameters are shown on the Pump Quick Setting menu depending on the A1-06 selection:
A1-03 = 6008
(A1-06 = 8)
Pressure Control
A1-03 = 6009
(A1-06 = 9)
Pump Down
Level
A1-03 = 6010
(A1-06 = 10)
Geothermal
Mode
A1-03 = 6011
(A1-06 = 11)
VTC Pressure Ctl
A1-03 = 6012
(A1-06 = 12)
Pivot Panel VTC
A1-03 = 6013
(A1-06 = 13)
Adv
PressureCtrl
A1-03 = 6014
(A1-06 = 14)
Pivot Panel
Submersible
A1-03 = 7770
(A1-06 = 1)
General Purpose
A1-03 = 7771
(A1-06 = 2)
Sub Mtr GP Oper
E2-01 E2-01 b1-02 E2-01 E2-01 E2-01 E2-01 b1-01 E2-01
E2-04 E2-04 E2-01 b1-02
b1-02 E2-20
<1>
b1-02
b1-02 E2-04
P1-03 P1-02 E2-04 b1-03 b1-03 P1-03 b1-03 C1-01 d1-01
Q1-01 P1-03 P1-06 b1-11 b1-11 Q1-01 b1-11 C1-02 P1-06
P1-04 Q1-01 Q2-01 C1-01 C1-01 P1-04 C1-01 E2-01 P4-10
P1-06 P1-04 Q2-02 C1-02 C1-02 P1-06 C1-02 E2-04 P5-04
P4-10 P1-06 Q2-03 P1-03 P1-03 P1-08 P1-03 L5-01
P5-04 P2-02 Q2-04 Q1-01 Q1-01 P1-09 Q1-01 L5-04
P4-10 Q2-05 P1-04 P1-06 L5-40 P1-06 P1-06
P5-04 Q2-06 P1-06 P1-08 P1-11 P1-08
Q2-07 P1-08 P1-09 P1-12 P1-09
Q2-08 P1-09 P1-11 L5-41 P1-11
Q2-09 P1-11 P1-12 P1-15 P1-12
Q2-10 P1-12 P4-01 P1-16 P4-01
Q2-11 P2-02 P4-02 L5-50 P4-02
Q2-12 P2-03 P4-03 P1-19 P4-03
P4-10 P4-01 Q3-01 P1-20 Q3-01
P5-04 P4-02 Q3-02 P1-23 Q3-02
P4-03 L5-51
Q3-01 P5-04
Q3-02 P4-10
<1> Available in drive software versions PRG: 8554 and later.
u
Parameters Set Depending on A1-08 Setting
The following table shows the parameters that are set depending on the A1-08 initialization:
A1-08 = 3005
(A1-06 = 5)
General Ext HOA
A1-08 = 3006
(A1-06 = 6)
General HOA Keys
Parameter Value Parameter Value
A1-02 0 A1-02 0
b1-01 1 b1-01 1
b1-02 1 b1-02 6
b1-03 0 b1-03 0
b1-15 2 b1-15 2
b1-16 2 b1-16 7
b5-01 0 b5-01 0
C1-01 25.0 s C1-01 25.0 s
C1-02 25.0 s C1-02 25.0 s
H1-02 26H H1-02 26H
H1-05 26H H1-05 26H
H1-08 2 H1-08 2
H2-01 0H H2-01 0H
H2-02 AH H2-02 AH
H3-02 20H H3-02 20H
4.5 Pump Application Presets
148
YASKAWA TOEP YAIP1W 01F YASKAWA AC Drive - iQpump1000 User Manual
