YASKAWA iQpump1000 - S6: Protection

No.
(Addr.
Hex)
Name LCD Display Description Values Page
S3-11
(3224)
Secondary PI Output
Level Selection
PI2 Out Lvl Sel
0: Direct Acting
1: Inverse Acting
Sets the secondary PI controller output direction.
0: Normal Output (direct acting)
1: Inverse Output (inverse acting)
Default: 0
Range: 0, 1
–
S3-12
(3225)
Secondary PI Disable
Mode
PI2 Disable Mode
0: No output
1: Lower Limit
2: Setpoint
Selects the secondary PI controller output when disabled.
0: No output (0%)
1: Lower Limit (S3-10)
2: Setpoint
Default: 0
Range: 0 to 2
–
S3-13
(3226)
Secondary PI Low
Feedback Detection
Level
PI2 Low FB Lvl
Sets the secondary PI low feedback detection level.
Default: 0.00
<1>
Min.: 0.00
Max.: 600.00
<2>
–
S3-14
(3227)
Secondary PI Low
Feedback Detection
Time
PI2 Low FB Time
Sets the secondary PI low feedback detection delay time in
seconds.
Default: 1.0 s
Min.: 0.0
Max.: 25.5
–
S3-15
(3228)
Secondary PI High
Feedback Level
PI2 High FB Lvl
Sets the secondary PI high feedback detection level.
Default: 100.00
<1>
Min.: 0.00
Max.: 600.00
<2>
–
S3-16
(3229)
Secondary PI High
Feedback Detection
Time
PI2 High FB Tim
Sets the secondary PI high feedback detection delay time in
seconds.
Default: 1.0 s
Min.: 0.0
Max.: 25.5
–
S3-17
(322A)
Secondary PI Feedback
Detection Selection
PI2 FB Det Sel
0: PI2 Enabled
1: Always
Selects when secondary PI controller low and high feedback
detection are active.
0: Secondary PI enabled
1: Always
Default: 0
Range: 0, 1
–
<1> Unit is determined by S3-04.
<2> Upper limit is S3-02, decimal placeholder is determined by S3-03.
u
S6: Protection
No.
(Addr.
Hex)
Name LCD Display Description Values Page
S6-01
(3236)
Emergency Override
Speed
E Override Speed
Sets the speed command used in emergency override mode
when S6-02 = 0.
Default: 0.00 Hz
Min.: 0.00
Max.: 400.00
–
S6-02
(3237)
Emergency Override
Reference Selection
E OverrideRefSel
0: Use S6-01 Ref
1: Use Freq Ref
Selects the emergency override speed source.
0: Use S6-01 Reference
1: Use Frequency Reference
Default: 0
Range: 0, 1
–
S6-07
(323C)
Output Phase Loss
Level for Dynamic
Noise Control
DNC Outp Ph Loss
Reduces the output phase loss level when Dynamic Noise
Control is active.
Default: 100.0%
Min.: 10.0
Max.: 100.0
–
B.14 S: Special Application
YASKAWA TOEP YAIP1W 01F YASKAWA AC Drive - iQpump1000 User Manual
435
B
Parameter List
