YASKAWA iQpump1000 - Parameters Displayed Depending on A1-08 Setting

A1-08 = 3005
(A1-06 = 5)
General Ext HOA
A1-08 = 3006
(A1-06 = 6)
General HOA Keys
Parameter Value Parameter Value
H3-06 1FH H3-06 1FH
H3-10 0 H3-10 0
L5-04 180.0 s L5-04 180.0 s
o1-06 0 o1-06 0
P1-05 0 s P1-05 0 s
P1-06 0.0 Hz P1-06 0.0 Hz
P4-12 0.0 Hz P4-12 0.0 Hz
P4-17 0.0 min P4-17 0.0 min
P5-01 0 P5-02 0.0 Hz
P5-03 1 P5-03 1
P5-04 0
u
Parameters Displayed Depending on A1-08 Setting
The following table shows which parameters are shown on the Pump Quick Setting menu depending on the A1-08 selection:
A1-08 = 3005
(A1-06 = 5)
General Ext HOA
A1-08 = 3006
(A1-06 = 6)
General HOA Keys
C1-01 C1-01
C1-02 C1-02
E2-01 E2-01
E2-04 E2-04
H1-02 H1-02
H1-03 H1-03
H1-05 H1-05
H1-22 H1-22
H1-23 H1-23
H1-25 H1-25
L5-01 L5-01
L5-04 L5-04
P1-06 P1-06
P5-05 P5-02
4.5 Pump Application Presets
