YASKAWA iQpump1000 - Q6: PI Auxiliary Control

No.
(Addr.
Hex)
Name LCD Display Description Values Page
Q5-20
(0F36)
<3>
Suction Pressure Speed
Control
SucPres Spd Ctrl
0: Disabled
1: Enabled
Selects whether the Suction Pressure Controller has an effect on
output speed.
0: Disabled
1: Enabled
Default: 1
Range: 0, 1
–
Q5-22
(0F38)
<4>
Suction Pressure
Decimal Place Position
Suc Press Dec Pt
0: No Dec (XXXXX)
1: 1 Dec (XXXX.X)
2: 2 Dec (XXX.XX)
3: 3 Dec (XX.XXX)
Sets the number of decimal places for the Suction Pressure
parameters and monitor:
0: No Dec (XXXXX)
1: 1 Dec (XXXX.X)
2: 2 Dec (XXX.XX)
3: 3 Dec (XX.XXX)
Default: 1
Range: 0 to 3
–
Q5-25
(0F3B)
<4>
Suction Pressure
Control Activation
Level
SucPress Act Lvl
When the suction pressure drops below this level for more than
the Q5-26 time, Suction Pressure Control is activated allowing
it to affect the output frequency. When the suction pressure rises
above this level for more than the Q5-26 time, Suction Pressure
is deactivated causing it to have no effect on the output
frequency.
Suction Pressure Control is always active (if enabled) when set
to 0.
Default: 10.0
PSI
Range: 0.0 to
1200.0
<1>
–
Q5-26
(0F3C)
<4>
Suction Pressure
Control Activation/
Deactivation Delay
SucPress Act Dly
When the suction pressure drops below the Q5-25 level for more
than this time, Suction Pressure Control is activated allowing it
to affect the output frequency. When the suction pressure rises
above the Q5-25 level for more than this time, Suction Pressure
Control is deactivated causing it to have no effect on the output
frequency.
Default: 2 s
Range: 0 to
3600
–
<1> Units are determined by Q5-01, Suction Pressure Select, setting.
<2> Units are determined by Q5-18, Suction Pressure Detection Time Unit, setting.
<3> Available in drive software versions PRG: 8552 and later. Not available in drive models 4A0930 and 4A1200.
<4> Available in drive software versions PRG: 8554 and later. Not available in drive models 4A0930 and 4A1200.
u
Q6: PI Auxiliary Control
No.
(Addr.
Hex)
Name LCD Display Description Values Page
Q6-01
(0F50)
<1>
PI Auxiliary Control
Selection
PI Aux Ctrl Sel
0: Disabled
1: Enabled
Sets the mode of operation for the PI Auxiliary Control function.
0: Disabled
1: Enabled
Default: 0
Range: 0, 1
–
Q6-02
(0F51)
<1>
PI Auxiliary Control
Feedback Scale
PI Aux Lvl Scale
Sets the full scale (10 V or 20 mA) output of the pressure
transducer connected to the analog input terminal programmed
for “PI Aux FB Level” (H3-oo = 27).
Default: 145.0
PSI
<3>
Min.: 1.0
Max.: 6000.0
–
Q6-03
(0F52)
<1>
PI Auxiliary Control
Setpoint
PI Aux Setpoint
Sets the level to which the drive will attempt to regulate.
Default: 20.0
PSI
<3>
Min.: 0.0
Max.: 6000.0
–
Q6-04
(0F53)
<1>
PI Auxiliary Control
Minimum Level
PI Aux Min Lvl
Sets the level below which the drive must fall for longer than
the time set in Q6-05 time before the drive goes to sleep and
turns off all lag pumps.
Note: This feature is disabled when set to 0.0.
Default: 10.0
PSI
<3>
Min.: 0.0
Max.: 6000.0
–
Q6-05
(0F54)
<1>
PI Auxiliary Control
Sleep Delay Time
Sleep Dly Time
Inverse Acting (Q6-23 = 1): Sets the amount of time that the
drive will delay before going to sleep after the level drops below
Q6-04 setting.
Normal Acting (Q6-23 = 0): Sets the amount of time that the
drive will delay before going to sleep after the level rises above
Q6-24 setting Range: 0 to 3600 s Default 5 s
Default: 5 s
Min.: 0
Max.: 3600
–
