Drive Model Terminal
Recomm.
Gauge With
Additional
Impedance
AWG, kcmil
Screw
Size
JST Ring Terminal
(non-insulated)
JST
Recomm.
Installation
Tool
JST
Crimphead /
Die Part No.
Insulation Cap
Model No.
5o0077
5o0099
R/L1, S/L2 4
M10
R22-10
YA-5
AD-953 TP-022
U/T1, V/T2, W/T3 8 R8-10 AD-951 TP-008
5o0125
R/L1, S/L2 1
M10
R38-10
YA-5
AD-954 TP-038
U/T1, V/T2, W/T3 6 R14-10 AD-952 TP-014
5o0145
R/L1, S/L2 1
M10
R38-10
YA-5
AD-954 TP-038
U/T1, V/T2, W/T3 6 R14-10 AD-952 TP-014
5o0192
R/L1, S/L2 3/0
M12
80-L12
YF-1
YET-300-1
TD-323,
TD-312
TP-080
U/T1, V/T2, W/T3 3 R38-12 YA-5 AD-954 TP-038
5o0242
R/L1, S/L2 3/0
M12
80-L12
YF-1
YET-300-1
TD-323,
TD-312
TP-080
U/T1, V/T2, W/T3 3 R38-12 YA-5 AD-954 TP-038
A.4 Drive Derating Data
YASKAWA TOEP YAIP1W 01F YASKAWA AC Drive - iQpump1000 User Manual
347
A
Specifications
