Flange Type Heat Loss Data
Table 2.16 Models 2A0056, 4A0038, and 5A0017 and 5A0022
Drive Model
Voltage
Class
Heat Loss (W)
Wt. kg (lb)ND (Fc = 2 kHz) HD (Fc = 8 kHz)
Internal External Total Internal External Total
2A0056 200 175.4 370.7 546.1 129.9 280.2 410.1 5.9 (13.0)
Drive Model
Voltage
Class
Heat Loss (W)
Wt. kg (lb)ND (Fc = 2 kHz) HD (Fc = 8 kHz)
Internal External Total Internal External Total
4A0038 400 181.6 339.6 521.2 140.8 262.6 403.4 6.0 (13.2)
Drive Model
Voltage
Class
Heat Loss (W)
Wt. kg (lb)ND (Fc = 2 kHz) HD (Fc = 8 kHz)
Internal External Total Internal External Total
5A0017
600
146.7 96.6 243.3 67.5 144.7 212.2 6.0 (13.2)
5A0022 178.3 99.4 277.7 81.1 203.8 284.9 6.0 (13.2)
