5 Operation
5.9.1 Connecting the Absolute Encoder
5-62
5.9.1 Connecting the Absolute Encoder
The following diagram shows the connection between a servomotor with an absolute encoder, the multi-wind-
ing drive unit, and the host controller.
(1) Using an Encoder Cable with a Battery Case
∗1. The absolute encoder pin numbers for the connector wiring depend on the servomotors.
∗2. To prevent the influence of external noise, we recommend you connect a ferrite core on the motor end of the encoder
cable using two turns.
∗3. : represents shielded twisted-pair wires.
∗4. When using an absolute encoder, provide power by installing an encoder cable with a JUSP-BA01-E Battery Case or
install a battery on the host controller.
/PCO
4
2
SG
SEN
33
34
35
36
19
20
CN1
SG
1
PA
O
/P
AO
PBO
/PBO
PCO
Multi-winding drive unit
Connector
shell
CN1
∗4
0 V
+5 V
Host controller
R
R
R
3
4
CN21
Connector
shell
5
6
1
2
Output line-driver
SN75ALS174
manufactured by Texas
Instruments or
the equivalent
Phase A
Phase B
Phase C
Phase A
Phase B
Phase C
Applicable line receiver: SN75ALS175
or MC3486 manufactured by Texas
Instruments or the equivalent
Terminating resistance R: 220 to 470 Ω
Battery
Encoder cable
with battery case
∗4
ENC
∗3
∗1, ∗2
PG5 V
PG0 V
PS
/PS
BAT(+)
BAT(-)
Absolute encoder
FG
+
-
