10 Appendix
10-34
10.3 List of Monitor Displays
The following list shows the available monitor displays.
∗1.
For details, refer to
8.4 Monitoring Input Signals
.
∗2.
For details, refer to
8.5 Monitoring Output Signals
.
∗3.
For details, refer to
8.3 Reading 32-bit Data in Decimal Displays
.
∗4.
For details, refer to
5.4.4 Electronic Gear
.
∗5.
If the reference pulse input multiplication switching function is enabled, the reference pulse will be multiplied by n to
obtain the reference.
Parameter
No.
Description Unit
Un000
Motor rotating speed
min
-1
Un001
Speed reference
min
-1
Un002
Internal torque reference (percentage of the rated torque) %
Un003
*3
Rotational angle 1 (encoder pulses from the phase-C origin:
decimal display)
encoder pulse
∗4
Un004
Rotational angle 2 (from polarity origin (electric angle)) deg
Un005
*1
Input signal monitor
−
Un006
*2
Output signal monitor
−
Un007
*6
Input reference pulse speed (valid only in position control)
min
-1
Un008
*6
Position error amount (valid only in position control) reference unit
Un009
Accumulated load ratio (in percentage to the rated torque:
effective torque in cycle of 10 seconds)
%
Un00A
Regenerative load ratio (as a percentage of the processable
regenerative power: regenerative power consumption in cycle
of 10 seconds)
%
Un00B
Power consumed by DB resistance
(in percentage to the processable power at DB activation: dis-
played in cycle of 10 seconds)
%
Un00C
*3,*5
Input reference pulse counter reference unit
Un00D
*3
Feedback pulse counter
encoder pulse
∗4
Un012
Total operation time 100 ms
Un013
*3
Feedback pulse counter reference unit
Un014
Effective gain monitor (gain settings 1 = 1, gain settings 2 = 2)
−
Un015
Safety I/O signal monitor
−
Un020
Motor rated speed
min
-1
Un021
Motor maximum speed
min
-1
