1.6.1 Multi-Winding Drive Unit Model Designation
1-14
1.6 Model Designations
1.6.1 Multi-Winding Drive Unit Model Designation
This section shows the multi-winding drive unit model designation.
Note: When digits 8 to 13 are all zeros (0) in the model designation, the zeros are not shown.
D
4th digit: Main Circuit Power
Supply Voltage
Code Voltage
D
DC power input from
separate 400-VAC converter
4th
digit
JUSP
Series
JUSP
Servo peripheral
devices
MD 01 A
1st + 2nd digits
MD
Multi-winding drive unit
5th + 6th digits: Interface Specifications
Code Interface
01
Analog voltage and pulse train
reference, rotational servomotor
1st + 2nd
digits
5th + 6th
digits
7th
digit
–
7th digit: Design
Revision Order
000
8th + 9th +
10th digits
00
11th + 12th
digits
11th + 12th digits: Software
Specification
Code Specification
00 Standard
0
13th
digit
13th digit: Parameter
Specification
Code Specification
0 Standard
8th + 9th + 10th digits: Hardware Specifications
Code Specification
000 Base-mounted (standard)
001 Duct-ventilated
002 Varn is he d
003 Duct-ventilated and varnished
3
3rd
digit
3rd digit: Power Supply
Capacity (Maximum
Applicable Motor)
3
75 kW
