7 Utility Functions (Fn)
7-26
(2) Operating Procedure
Use the following procedure.
Step Display after Operation Keys Operation
1
Press the Key to view the main menu for the
utility function.
Use the or Key to move through the list and
select Fn01E.
2
Press the Key. The display changes to the Fn01E
(multi-winding drive unit and motor ID check) exe-
cution display. The multi-winding drive unit ID infor-
mation is displayed. Use the or Key to
scroll left and right and to view other information.
3
Press the Key.
The servomotor ID information is displayed. Use the
or Key to scroll left and right and to view
other information.
4
Press the Key.
The encoder ID information is displayed.
Use the or Key to scroll left and right and to
view other information.
5
Press the Key.
The display returns to the main menu of the utility
function.
RUN − FUNCTION−
Fn01B:Viblvl Init
Fn01E:SvMotOp ID
Fn01F:FBOpMot ID
Fn020:S− Orig Set
Rotation
BB − SvMotOp ID−
Driver
SGDV− 750J01A
D00241234590001
12. 07 400V, 22000W
Serial number
Manufacturing
date
Multi-winding drive unit model
SERVOPACK
input voltage
SERVOPACK
capacity
Analog
Servomotor order number
Manufacturing
date
Servomotor model
Servomotor
voltage
Servomotor
capacity
BB − SvMotOp ID−
Motor
SGMVV− 7EDDB
123456− 1 − BK1
12. 07 400V, 75000W
BB ޓ − SvMotOp ID−
Encoder
UTTIH− B20FN
Q12345− 001− BK6
12. 07 20bit− INC
Encoder serial number
Manufacturing
date
Encoder model
Encoder
resolution
Encoder
type
Rotation
RUN − FUNCTION−
Fn01B:Viblvl Init
Fn01E:SvMotOp ID
Fn01F:FBOpMot ID
Fn020:S− Orig Set
Ro-
ta-
tion
