YASKAWA JUSP-MD D01A Series - Page 83

3.7 Encoder Connection
3-37
3
Wiring and Connection
(2) Absolute Encoder
∗1. The pin arrangement for wiring connectors varies in accordance with the servomotor that is used.
∗2. To prevent the influence of external noise, we recommend you connect a ferrite core on the motor end of the encoder
cable using two turns.
∗3. : represents shielded twisted-pair wires.
∗4. When using an absolute encoder, provide power by installing an encoder cable with a JUSP-BA01-E Battery Case or
install a battery on the host controller.
• When Installing a Battery on the Encoder Cable
Use the encoder cable with a battery case that is specified by Yaskawa.
Refer to the multi-winding drive system catalog for details.
• When Installing a Battery on the Host Controller
Insert a diode near the battery to prevent reverse current flow.
/PCO
21
22
BAT
BAT
(+)
(-)
33
34
35
36
19
20
CN1
PA
O
/P
AO
PBO
/PBO
PCO
Multi-winding drive unit
Phase A
Phase B
Phase C
Connector
shell
CN1
∗3
∗4
Host controller
Battery
Phase A
Phase B
Phase C
R
R
R
R (terminating resistance): 220 to 470 Ω
Applicable line receiver:
SN75ALS175 or MC3486
manufactured by Texas
Instruments, or the equivalent
SG
1
0 V
ENC
3
4
CN21
Absolute encoder
Connector
shell
∗3
∗1 ∗2
5
6
1
2
PG5 V
PG0 V
PS
FG
/PS
BAT(+)
BAT(-)
Output line-driver SN75ALS174
manufactured by Texas
Instruments or the equivalent
+
-
MECHA
Circuit Example
+
-
Battery
