6.2 Motion Command Details
6.2.4 Interpolation (INTERPOLA
TE)
6-39
Motion Commands
( 4 )
Tim
ing Charts
[ a ]
Normal Exec
ution
[ b ]
Execution when an Alarm Occurs
OW
08 = 4 (INTERPOLA
TE)
IW
08 = 4 (INTERPOLA
TE)
IW
09, bit 0 (BUSY)
IW
09, bit 8 (COMPLETE)
IW
09, bit 3 (F
AIL)
IW
0C, bit 0 (DEN)
IW
0C, bit 1 (POSCOMP)
Undefined length of time
1 scan
The target position is refreshed every high-speed scan.
Undefined length of time
IW
0C, bit 1 (POSCOMP)
1 scan
Alarm
OW
08 = 4 (INTERPOLA
TE)
IW
08 = 4 (INTERPOLA
TE)
IW
09, bit 0 (BUSY)
IW
09, bit 8 (COMPLETE)
IW
09, bit 3 (F
AIL)
IW
0C, bit 0 (DEN)
203
