6.2 Motion Command Details
6.2.25 Change Position Loop Integral Time Constant (KIS)
6-93
Motion Commands
6.2.25 Change Position Loop Integral Time Constant (KIS)
The KIS command transfers the setting of the Position Integration Time Constant (motion setting parameter
OW32) to the Position Integration Time Constant in the SERVOPACK and enables the setting.
 MECHATROLINK-II has a function that automatically updates setting parameters if a parameter changes. There is
no need to execute the KIS command with this function. For details, refer to bit A (User Constants Self-writing Func-
tion) in 4.4.1 ( 2 ) Function Selection 1.
( 1 ) Executing/Operating Procedure
1. Check to see if all the following conditions are satisfied.
2. Set OW08 to 26 to execute the KIS motion command.
The KIS command will transfer the setting of the Position Integration Time Constant (motion setting parameter
OW32) to the Position Integration Time Constant in the SERVOPACK and enables the setting.
IW08 will be 26 during command execution.
IW09, bit 0 will turn ON during the command processing and will turn OFF when the command processing
has been completed.
3. Set OW08 to 0 to execute the NOP motion command and then complete the change of the position
loop integration time.
( 2 ) Holding and Aborting
The Holds a Command bit (OW09, bit 0) and the Interrupt a Command bit (OW09, bit 1) cannot be used.
When the tuning-less function of the SGDV or SGD7S SERVOPACK is enabled or when the SERVOPACK parameter
Pn170.0 is set to 1 (Tuning-less Function Selection is enabled), these settings are disabled and ignored.
( 3 ) Related Parameters
[ a ] Setting Parameters
[ b ] Monitoring Parameters
No. Execution Conditions Confirmation Method
1 There are no alarms. Both IL02 and IL04 are 0.
2 Motion command execution has been completed. IW08 is 0 and IW09 bit0 is OFF.
Parameter Name Setting
OW08 Motion Command
The feed forward is changed when this parameter is set to 26.
OW09
Bit 0
Holds a Command
This parameter is ignored for KIS command.
OW09
Bit 1
Interrupt a Command
This parameter is ignored for KIS command.
OW32
Position Integration
Time Constant
Set the integration time constant for the position loop in milliseconds.
Parameter Name Monitor Contents
IL02 Warning
Stores the most current warning.
IL04 Alarm
Stores the most current alarm.
IW08
Motion Command Re-
sponse Cable
Indicates the motion command that is being executed.
The response code will be 26 during KIS command execution.
IW09
Bit 0
Command Execution
Flag
Turns ON during KIS command execution and turns OFF when execution has been
completed.
IW09
Bit 1
Command Hold
Completed
Always OFF for KIS command.
IW09
Bit 3
Command Error
Completed Status
Turns ON if an error occurs during KIS command execution.
Turns OFF when another command is executed.
