2.2 Applicable Machine Controllers for SVB-01 Modules
2-6
2.2 Applicable Machine Controllers for SVB-01 Modules
The following table lists the MP2000-series Machine Controllers on which the SVB-01 Module can be mounted.
* 1. Mount a CPU module on the following base units.
* 2. The following module or board is required between racks.
Name Model
Max. No. of
Connectable
Modules
Applicable Version
Remarks
CPU Module MPE720
MP2300
JEPMC-MP2300 (-E) 2 modules Ver. 2.44 or later
Ve r. 5. 3 3
Ve r. 6. 0 1
Ve r. 7. 1 0
or later
–
MP2310
JEPMC-MP2310 (-E) 3 modules
All versions
–
MP2300S
JEPMC-MP2300S (-E) 1 module –
MP2200
*1
CPU-01
JAPMC-CP2200 (-E)
16 modules
The maximum number
of connectable Modules
is the total for the maxi-
mum expansion to four
racks.
*2
CPU-02
JAPMC-CP2210 (-E)
CPU-03
JAPMC-CP2220-E
CPU-04
JAPMC-CP2230-E
MP2100M
JAPMC-MC2140 (-E)
13 modules
Ver. 2.44 or later
The maximum number
of connectable Modules
is the total for the maxi-
mum expansion to three
racks.
*2
MP2101M
JAPMC-MC2142-E
All versions
Ve r. 5. 5 4
Ve r. 6. 2 4
Ve r. 7. 1 0
or later
MP2101TM
JAPMC-MC2142T-E
Name Model Remarks
MBU-01
JEPMC-BU2200 (-E) 100/200-VAC input base unit (9 slots)
MBU-02
JEPMC-BU2210 (-E) 24-VDC input base unit (9 slots)
MBU-03
JEPMC-BU2220-E 24-VDC input base unit (4 slots)
Name Model Remarks
EXIOIF
JAPMC-EX2200 (-E) Inter-rack connection module
MP2100MEX
JAPMC-EX2100 (-E) I/F board for MP2100M, MP2101M, and MP2101TM
