YASKAWA MP Series User Manual

1.1 SVB Module Overview and Features
1.1.5 Devices Connectable to MECHATROLINK
1-4
1.1.5 Devices Connectable to MECHATROLINK
The devices that are compatible with MECHATROLINK and can be connected to the SVB Module are listed below.
( 1 ) SERVOPACKs and Inverters
The following table shows SERVOPACKs that are compatible with MECHATROLINK and can be connected to the
SVB Module.
( 2 ) I/O Modules
The following table shows Modules that are compatible with MECHATROLINK and can be connected to the SVB
Module.
Type Model Number Details MECHATROLINK-I MECHATROLINK-II
SERVOPACKs
SGD-N
SGDB-AN
MECHATROLINK-I-compatible AC
SERVOPACK
Yes No
SGDH-E
JUSP-NS100
Σ-II Series SGDH SERVOPACK
NS100 MECHATROLINK-I
Application Module
Yes No
SGDH-E
JUSP-NS115
Σ-II Series SGDH SERVOPACK
NS115 MECHATROLINK-II
Application Module
Yes Yes
SGDS-1
Σ-III Series SGDS SERVOPACK
Yes Yes
SGDX-12
SGDX SERVOPACK
Yes Yes
SJDE-AN
SJDE SERVOPACK
No Yes
SGDV-
1
SGDV SERVOPACK
Yes Yes
SGD7S-
10
SGD7S SERVOPACK
Yes Yes
Inverters
CIMR-G7A
SI-T
Varispeed G7 Inverter
with MECHATROLINK interface
Yes Yes
CIMR-F7A
SI-T
Varispeed F7 Inverter
with MECHATROLINK interface
Yes Yes
CIMR-V7AA
SI-T/V7
VSmini V7 Inverter
with MECHATROLINK interface
Yes Yes
CIMR-A
SI-T3
High Performance Vector Control Drive A1000
MECHATROLINK-II Option Card
Yes Yes
CIMR-V
SI-T3/V
Compact Vector Control Drive V1000
MECHATROLINK-II Option Unit
Yes Yes
Model Number Details MECHATROLINK-I MECHATROLINK-II
JEPMC-IO350
64-point I/O Module
24 VDC, 64 inputs, 64 outputs (sink)
Yes No
JAMSC-120DDI34330
DC Input Module 12/24 VDC, 16 inputs
Yes No
JAMSC-120DDO34340
DC Output Module 12/24 VDC, 16 outputs
Yes No
JAMSC-120DAI53330
AC Input Module 100 VAC, 8 inputs
Yes No
JAMSC-120DAI73330
AC Input Module 200 VAC, 8 inputs
Yes No
JAMSC-120DAO83330
AC Output Module 100/200 VAC, 8 outputs
Yes No
JAMSC-120DRA83030
Relay Module
Wide voltage range relay contacts, 8 contact
outputs
Yes No
JAMSC-120AVI02030
A/D Module
Analog inputs, -10 to 10 V, 4 channels
Yes No
JAMSC-120AVO01030
D/A Module
Analog outputs, -10 to 10 V, 2 channels
Yes No
JAMSC-120EHC21140
Counter Module
Reversible counter, 2 channels
Yes No
JAMSC-120MMB20230
Pulse Output Module, Pulse output, 2 channels
Yes No
