YASKAWA MP Series User Manual

9.4 Absolute Position Detection for Infinite Length Axes
9.4.1 Simple Absolute Infinite Length Position Control
9-14
 System That Satisfies the Above Condition
The following example shows the system that can use the Simple Absolute Infinite Length Position Control function.
Reset number of turns = (360000 × 6) / (360000 × 5) = 6/5
Criterion to use Simple Absolute Infinite Length Position Control : (59705 + 1) / (6/5) = 49755
The Simple Absolute Infinite Length Position Control can be used since the result of the above equation is an integer
(remainder 0).
Fixed Parameter
No.
Name Setting Value
4
Reference Unit Selection
2 (deg)
6
Travel Distance per Machine Rotation
360000
8
Servo Motor Gear Ratio
6
9
Machine Gear Ratio
5
10
Infinite Length Axis Reset Position
(POSMAX)
360000
36
Number of Pulses per Motor Rotation
16384
38
Maximum Number of Absolute
Encoder Turns Rotation
59705
