Monitoring Parameters
( 4 ) Write User Constant
Description
Writes the specified inverter user constant to a constant in the Inverter.
Valid when using MECHATROLINK-II 17-byte mode and MECHATROLINK-I.
Use the subcommand when using MECHATROLINK-II 32-byte mode.
With Varispeed G7and F7, it is necessary to execute the command User Constant RAM Writing (see
( 7 ) User Constant RAM Writing) to validate the data written by executing Write User Constant.
With VSminiV7, the data written by executing Write User Constant will be immediately validated.
Setting Parameters
Name Register No.
Setting
Range
Remarks
Command Response Code
IW08 0 to 8 02: Read User Constant
Command Status
IW09 Bit
Bit 0 (Command execution flag) ON during execution
Bit 3 (Command error completed
status)
ON when an error
occurs during com-
mand processing
Bit 8 (Command execution com-
pleted)
ON when command
execution is com-
pleted.
Status
IW10 Bit Inverter status
Response Alarm Code
IW30 0 to FFFFH Inverter alarm code
Inverter User Constant Number
IW3C 0 to FFFFH
User Constant
Reading Data 1
IW3E 0 to 65535
User Constant
Reading Data 2
IW3F 0 to 65535
User Constant
Reading Data 3
IW40 0 to 65535
User Constant
Reading Data 4
IW41 0 to 65535
Name Register No. Setting Range Remarks
Command Code
OW08 0 to 8 03: Write User Constant
Inverter User Constant Number
OW3C 0 to FFFFH
Inverter User Constant Number
Size
OW3D 1 to 4
Data type: Word (Enter the size of the user constant
read out from the leading user constant number of the
inverter.)
Inverter User Constant
Set Point 1
OW3E 0 to 65535
Inverter User Constant
Set Point 2
OW3F 0 to 65535
Inverter User Constant
Set Point 3
OW40 0 to 65535
Inverter User Constant
Set Point 4
OW41 0 to 65535
