10.5 Inverter Alarm and Warning Codes
10.5.5 Optional Interface Settings
10-52
( 2 ) S2: Hexadecimal Rotary Switch
( 3 ) Station Address List: S1-3 and S2 Switches
* 1. The station address cannot be used because of the design of the inverters.
* 2. The station address cannot be used because of the design of the SVB Module.
Device
Code
Switch Name Status Description
S2
SA 0 to F Sets the first digit of the station address 0H to FH in hexadecimal.
S1-3 S2
Station Address (ST#)
Station Address in Network Analyzer for
MECHATROLINK Communications
Decimal
Number
Hexadecimal
Number
OFF
0
–
*1
–
*1
–
*1
1101H 21H
2202H 22H
3303H 23H
4404H 24H
5505H 25H
6606H 26H
7707H 27H
8808H 28H
9909H 29H
A100AH 2AH
B 11 0BH 2BH
C 12 0CH 2CH
D130DH 2DH
E140EH 2EH
F150FH 2FH
ON
01610H 30H
1 to E
–
*2
–
*2
–
*2
F
–
*1
–
*1
–
*1
To Next Page
