YASKAWA P7 User Manual

Physical Installation 1 - 2
Model Number and Enclosure Style
Table 1.1 Model Numbers and Enclosure Style
Input
Voltage
3-Phase
Model-Number Enclosure Style
Rated
Output
Current
Nominal
Hp
208-240Vac
CIMR-P7U20P4 NEMA Type 1 (IP20) 3.6 0.5/0.75
CIMR-P7U20P7 NEMA Type 1 (IP20) 4.6 1
CIMR-P7U21P5 NEMA Type 1 (IP20) 7.8 1.5/2
CIMR-P7U22P2 NEMA Type 1 (IP20) 10.8 3
CIMR-P7U23P7 NEMA Type 1 (IP20) 16.8 5
CIMR-P7U25P5 NEMA Type 1 (IP20) 23.0 7.5
CIMR-P7U27P5 NEMA Type 1 (IP20) 31.0 7.5/10
CIMR-P7U2011 NEMA Type 1 (IP20) 46.2 15
CIMR-P7U2015 NEMA Type 1 (IP20) 59.4 20
CIMR-P7U2018 NEMA Type 1 (IP20) 74.8 25
CIMR-P7U2022 NEMA Type 1 (IP20) 88.0 30
CIMR-P7U2030 NEMA Type 1 (IP20) 115.0 40
208-230Vac
CIMR-P7U2037 Open Chassis (IP00) 162.0 50/60
CIMR-P7U2045 Open Chassis (IP00) 192.0 60/75
CIMR-P7U2055 Open Chassis (IP00) 215.0 75
CIMR-P7U2075 Open Chassis (IP00) 312.0 100/125
CIMR-P7U2090 Open Chassis (IP00) 360.0 125/150
CIMR-P7U2110 Open Chassis (IP00) 415.0 150
480 Vac
CIMR-P7U40P4 NEMA Type 1 (IP20) 1.8 0.5/0.75
CIMR-P7U40P7 NEMA Type 1 (IP20) 2.1 1
CIMR-P7U41P5 NEMA Type 1 (IP20) 3.7 1.5/2
CIMR-P7U42P2 NEMA Type 1 (IP20) 5.3 3
CIMR-P7U43P7 NEMA Type 1 (IP20) 7.6 5
CIMR-P7U45P5 NEMA Type 1 (IP20) 12.5 7.5
CIMR-P7U47P5 NEMA Type 1 (IP20) 17.0 10
CIMR-P7U4011 NEMA Type 1 (IP20) 27.0 15/20
CIMR-P7U4015 NEMA Type 1 (IP20) 34.0 25
CIMR-P7U4018 NEMA Type 1 (IP20) 40.0 30
CIMR-P7U4030 NEMA Type 1 (IP20) 67.2 40/50
CIMR-P7U4037 NEMA Type 1 (IP20) 77.0 60
CIMR-P7U4045 NEMA Type 1 (IP20) 96.0 75
CIMR-P7U4055 NEMA Type 1 (IP20) 125.0 100
CIMR-P7U4075 Open Chassis (IP00) 156.0 125
CIMR-P7U4090 Open Chassis (IP00) 180.0 150
CIMR-P7U4110 Open Chassis (IP00) 240.0 200
CIMR-P7U4160 Open Chassis (IP00) 304.0 250
CIMR-P7U4185 Open Chassis (IP00) 414.0 300/350
CIMR-P7U4220 Open Chassis (IP00) 515.0 400/450
CIMR-P7U4300 Open Chassis (IP00) 675.0 500+

YASKAWA P7 Specifications

General

Manufacturer	Yaskawa
Model	P7
Number of I/O Points	Varies by configuration
Storage Temperature	-20°C to 60°C
Dimensions	Varies depending on model (refer to specific model datasheet)
Weight	Varies depending on model (refer to specific model datasheet)
