YASKAWA P7 User Manual

Physical Installation 1 - 11
Heat Loss Data
Table 1.3 200V Class Heat Loss Data
TYPE
CIMR-P7U"
Drive
(Inverter)
Capacity
(kVA)
Rated
Output
Current
(A)
Cooling
Fin Side
(W)
Internal
Unit Side
(W)
Total
Watt
Loss
(W)
Cooling
Method
20P4 1.4 3.6 19 39 58 Self
20P7 1.8 4.6 26 42 68 Self
21P5 3.0 7.8 48 50 98 Self
22P2 4.1 10.8 68 59 127 Self
23P7 6.4 16.8 110 74 184 Fan
25P5 8.8 23 164 84 248 Fan
27P5 12 31 219 113 332 Fan
2011 18 46.2 357 168 524 Fan
2015 23 59.4 416 182 597 Fan
2018 29 74.8 472 208 680 Fan
2022 34 88 583 252 835 Fan
2030 44 115 883 333 1217 Fan
2037 62 162 1010 421 1430 Fan
2045 73 192 1228 499 1727 Fan
2055 82 215 1588 619 2206 Fan
2075 120 312 1956 844 2800 Fan
2090 140 360 2194 964 3157 Fan
2110 160 415 2733 1234 3967 Fan

YASKAWA P7 Specifications

General

Manufacturer	Yaskawa
Model	P7
Number of I/O Points	Varies by configuration
Storage Temperature	-20°C to 60°C
Dimensions	Varies depending on model (refer to specific model datasheet)
Weight	Varies depending on model (refer to specific model datasheet)
