Specifications C - 2
Standard Drive Specifications
The standard Drive specifications are listed in the following tables.
! 208-240Vac
Table C.1 208-240Vac Drive Specifications
Model Number CIMR-P7U
20P4 20P7 21P5 22P2 23P7 25P5 27P5 2011 2015 2018 2022 2030
Rated output capacity (kVA) 1.4 1.8 3.0 4.1 6.4 8.8 12.0 18.0 23.0 29.0 34.0 44.0
Motor HP
208V 0.5/0.75 1 1.5/2 3 5 7.5 10 15 20 25 30 40
230V 0.5/0.75 1 1.5/2 3 5 7.5 10 15 20 25 30 40
Rated output current (A) 3.6 4.6 7.8 10.8 16.8 23.0 31.0 46.2 59.4 74.8 88.0 115.0
Max. output voltage (V) 3-phase; 200, 208, 220, 230, or 240Vac (Proportional to input voltage)
Max. output frequency (Hz) 120 Hz
Rated voltage (V)
Rated frequency (Hz)
3-phase, 200/208/220/230/240Vac, 50/60 Hz
Rated input current (A)
4.3 5.5 9.4 13 20 24 37 53 70 89 98 120
Allowable voltage fluctuation + 10%, - 15%
Allowable frequency fluctuation ±5%
Measures for
power supply
harmonics
DC Reactor Optional Built-in
12-Pulse
Rectification
Not possible Possible
Note: The maximum applicable motor output is given for a standard 4-pole motor. When selecting the actual motor and Drive, be sure that the Drive's
rated output current is applicable for the motor's rated current.
A phase-shifting transformer is required on the power supply for 12-pulse rectification.
Table C.1 208-230Vac Drive Specifications (Continued)
Model Number CIMR-P7U
2037 2045 2055 2075 2090 2110
Rated output capacity (kVA) 62.0 73.0 82 120.0 140.0 160.0
Motor HP
208V 50 60 75 100 125 150
230V 50/60 75 - 100/125 - 150
Rated output current (A) 162.0 192.0 215 312.0 360.0 415.0
Max. output voltage (V)
3-phase; 200, 208, 220, 230, or 240Vac
(Proportional to input voltage)
Max. output frequency (Hz) 120 Hz
Rated voltage (V)
Rated frequency (Hz)
3-phase, 200/208/220/230/240Vac, 50/60 Hz
Rated input current (A)
180 212 237 350 396 457
Allowable voltage fluctuation + 10%, - 15%
Allowable frequency fluctuation ±5%
Measures for
power supply
harmonics
DC Reactor Built-in
12-Pulse
Rectification
Possible
Note: The maximum applicable motor output is given for a standard 4-pole motor. When selecting the actual motor and Drive, be sure that the Drive's rated
output current is applicable for the motor's rated current.
A phase-shifting transformer is required on the power supply for 12-pulse rectification.
