YASKAWA P7 User Manual

Physical Installation 1 - 4
! Drive Model Numbers
The model number on the nameplate indicates the design specification, voltage, and rating of the Drive in alphanumeric codes.
Fig 1.2 Drive Model Number Structure
! Drive Enclosure and Revision Code
The Drive SPEC number on the nameplate indicates the voltage, Drive rating, enclosure type, and the revision code of the
Drive in alphanumeric codes.
Fig 1.3 SPEC Number Structure
TERMS
Open Chassis Type (IEC IP00)
Protected so that parts of the human body cannot reach electrically charged parts from the front when the
Drive is mounted in a control panel, also called (protected chassis).
NEMA Type 1 (IEC IP20)
The Drive is shielded from the exterior, and can thus be mounted to the interior wall of a building
(not necessarily enclosed in a control panel). The protective structure conforms to the standards of NEMA
Type 1 in the USA. All protective covers (Fig 1.4) must be installed to conform with IEC IP20 and NEMA Type
1 requirements.
No.
Spec
UL Specification
CIMR – P7 U 2 0 11
AC Drive
U
No.
Voltage
2
4
3-phase, 208-240Vac
3-phase, 480Vac
Rating
P7 Family
2
011 1 A
No.
2
4
Voltage
3-phase, 208 - 240Vac
3-phase, 480Vac
No.
Enclosure Type
0 Open chassis (IEC IP00)
1
NEMA Type 1 (IEC IP20)
Hardware Revision
Rating

YASKAWA P7 Specifications

General

Manufacturer	Yaskawa
Model	P7
Number of I/O Points	Varies by configuration
Storage Temperature	-20°C to 60°C
Dimensions	Varies depending on model (refer to specific model datasheet)
Weight	Varies depending on model (refer to specific model datasheet)
