Electrical Installation 2 - 8
! Main Circuit Terminal Functions
Main circuit terminal functions are summarized according to terminal symbols in Table 2.3. Wire the terminals correctly for
the desired purpose.
Table 2.3 Main Circuit Terminal Functions (208-240Vac and 480Vac)
Purpose Terminal Designation
Model: CIMR-P7U_ _ _ _
208-240Vac 480Vac
Main circuit power input
R/L1, S/L2, T/L3 20P4 to 2110 40P4 to 4300
R1/L11, S1/L21, T1/L31 2022 to 2110 4030 to 4300
Drive outputs U/T1, V/T2, W/T3 20P4 to 2110 40P4 to 4300
DC power input
1,
20P4 to 2110 40P4 to 4300
Braking Transistor
Unit Connection
3,
2022 to 2110 4030 to 4300
Braking Resistor
Unit Connection
B1, B2
20P4 to 2018 40P4 to 4018
DC reactor connection
1, 2
20P4 to 2018 40P4 to 4018
Ground 20P4 to 2110 40P4 to 4300
