YASKAWA P7 User Manual

Specifications C - 3
Table C.2 480Vac Drive Specifications
Model Number CIMR-P7U 40P4 40P7 41P5 42P2 43P7 45P5 47P5 4011 4015 4018
Rated output capacity (kVA) 1.4 1.6 2.8 4.0 5.8 9.5 13.0 21.0 26.0 30.0
Motor HP (460V) 0.5/0.75 1 1.5/2 3 5 7.5 10 15/20 25 30
Rated output current (A) 1.8 2.1 3.7 5.3 7.6 12.5 17.0 27.0 34.0 40.0
Max. output voltage (V) 3-phase; 380, 400, 415, 440, 460, or 480Vac (Proportional to input voltage.)
Max. output frequency (Hz) 120 Hz
Rated voltage (V)
Rated frequency (Hz)
3-phase, 380, 400, 415, 440, 460 or 480Vac, 50/60 Hz
Rated input current (A) 2.2 2.5 4.4 6.4 9.0 15 20 33 40 48
Allowable voltage fluctuation + 10%, - 15%
Allowable frequency fluctuation ±5%
Measures for
power supply
harmonics
DC Reactor Optional
12-pulse
Rectification
Not possible
Table C.2 480Vac Drive Specifications (Continued)
Model Number CIMR-P7U 4030 4037 4045 4055 4075 4090 4110 4160 4185 4220 4300
Rated output capacity (kVA) 51.0 59.0 73.0 95.0 120.0 140.0 180.0 230.0 315.0 390.0 510.0
Motor HP (460V) 40/50 60 75 100 125 150 200 250 300/350 400/450 500+
Rated output current (A) 67.2 77.0 96.0 125.0 156.0 180.0 240.0 304.0 414.0 515.0 675.0
Max. output voltage (V) 3-phase, 380, 400, 415, 440, 460 or 480Vac (Proportional to input voltage)
Max. output frequency (Hz) 120 Hz
Max. voltage (V)
Rated frequency (Hz)
3-phase, 380, 400, 415, 440, 460, or 480Vac, 50/60 Hz
Rated input current (A) 74 85 106 134 172 198 264 334 456 567 743
Allowable voltage fluctuation + 10%, - 15%
Allowable frequency fluctuation ±5%
Measures for
power supply
harmonics
DC Reactor Built-in
12-Pulse
Rectification
Possible
Note: The maximum applicable motor output is given for a standard 4-pole motor. When selecting the actual motor and Drive, be sure that the Drive's
rated output current is applicable for the motor's rated current.
A 3-wire phase-shifting transformer is required on the power supply for 12-pulse rectification.
O
utput rat
i
ngsPower supp
l
y c
h
aracter
i
st
i
cs
Control characteristics
O
utput rat
i
ngsPower supp
l
y c
h
aracter
i
st
i
cs
C
ontro
l
c
h
aracter
i
st
i
cs
