YASKAWA P7 User Manual

Spare Parts F - 3
Primary Spare Parts - 480Vac
Table F.2 480Vac Primary Spare Parts
Drive Model
CIMR-P7U
Nominal
Hp
Power PCB
(3PCB)
Gate Drive PCB
(3PCB)
Control PCB
(1PCB)
Terminal PCB
(2PCB)
Diode Module
40P4
0.5/0.75
ETP6170 82 N/A ETC618 021-S3010 E TC618141 Inside th e Power Mod ule
40P7
1
ETP617082 N/A ETC618021-S3010 ETC618141 Inside the Power Module
41P5
1.5/2
ETP617092 N/A ETC618021-S3010 ETC618141 Inside the Power Module
42P2
3
ETP617102 N/A ETC618021-S3010 ETC618141 Inside the Power Module
43P7
5
ETP617112 N/A ETC618021-S3010 ETC618141 Inside the Power Module
45P5
7.5
ETP617132 N/A ETC618021-S3010 ETC618141 Inside the Power Module
47P5
10
ETP617142 N/A ETC618021-S3010 ETC618141 Inside the Power Module
4011
15/20
ETP617152 N/A ETC618021-S3010 ETC618141 Inside the Power Module
4015
25
ETP617162 N/A ETC618021-S3010 ETC618141 SID003112 (D1)
4018
30
ETP617172 N/A ETC618021-S3010 ETC618141 SID000605 (D1)
4030
40/50
N/A ETC617151 ETC618021-S3010 ETC618141 SID003112 (D1,D2)
4037
60
N/A ETC617161 ETC618021-S3010 ETC618141 SID003112 (D1,D2)
4045
75
N/A ETC617171 ETC618021-S3010 ETC618141 SID000605 (D1,D2)
4055
100
N/A ETC617181 ETC618021-S3010 ETC618141 SID000605 (D1,D2)
4075
125
N/A ETC617190 ETC618021-S3010 ETC618141 SID003117 (D1,D2)
4090
150
N/A ETC617200 ETC618021-S3010 ETC618141 SID003117 (D1,D2)
4110
200
N/A ETC617210 ETC618021-S3010 ETC618141 SID003109 (D1,D6)
4160
250
N/A ETC617230 ETC618021-S3010 ETC618141 SID003119 (D1,D6)
4185
300/350
N/A ETC617240 ETC618021-S3010 ETC618141 SID003119 (D1,D6)
4220
400/450
N/A ETC617250 ETC618021-S3010 ETC618141 SID003131 (D1,D6)
4300
500+
N/A ETC617260 ETC618021-S3010 ETC618141 SID003119(D1,D12)
Table F.2 480Vac Primary Spare Parts (Continued)
Drive Model
CIMR-P7U
Nominal
Hp
Power Module Transistor Module DC Bus Fuse Heat Sink Fan Internal Fan
40P4
0.5/0.75
STR001298 (Q1) N/A FU-002029 (F1) N/A N/A
40P7
1
STR001298 (Q1) N/A FU-002029 (F1) N/A N/A
41P5
1.5/2
STR001298 (Q1) N/A FU-002029 (F1) N/A N/A
42P2
3
STR001298 (Q1) N/A FU-002029 (F1) FAN001066 (B1) N/A
43P7
5
STR001300 (Q1) N/A FU-002031 (F1) FAN001066 (B1) N/A
45P5
7.5
STR001302 (Q1) N/A FU-002031 (F1) FAN001066 (B1) N/A
47P5
10
STR001279 (Q1) N/A FU-002032 (F1) FAN001066 (B1,B2) N/A
4011
10
N/A STR001280 (Q1) FU-002037 (F1) FAN001066 (B1,B2) FAN001043 (B3)
4015
15/20
N/A STR001318 (Q1) FU-002038 (F1) FAN001065 (B1,B2) N/A
4018
25
N/A STR001318 (Q1) FU-002038 (F1) FAN001065 (B1,B2) FAN001043 (B3)
4030
30
N/A STR001324 (Q1) FU-002039 (F1) FAN001039 (B1,B2) N/A
4037
60
N/A STR001316 (Q1-Q3) FU-002040 (F1) FAN001044 (B1,B2) N/A
4045
75
N/A STR001317 (Q1-Q3) FU-002040 (F1) FAN001044 (B1,B2) N/A
4055
100
N/A STR001317 (Q1-Q3) FU-002101 (F1) FAN001044 (B1,B2) N/A
4075
125
N/A STR001294 (Q1-Q3) FU-002112 (F1) FAN001052 (B1,B2) FAN001054 (B4)
4090
150
N/A STR001336 (Q1-Q6) FU-002113 (F1) FAN001052 (B1,B2) FAN001054 (B4)
4110
200
N/A STR001336 (Q1-Q6) FU-002114 (F1) FAN001056 (B1,B2) FAN001054 (B4)
4160
250
N/A STR001322 (Q1-Q3) FU-000895 (F1) FAN001056 (B1,B2) FAN001054 (B4)
4185
300/350
N/A STR001339 (Q1-Q12) FU-000895 (F1) FAN001056 (B1,B4) FAN001054 (B6,B7)
4220
400/450
N/A STR001341 (Q1-Q12) FU-002116 (F1) FAN001056 (B1,B4) FAN001054 (B6,B7)
4300
500+
N/A STR001342 (Q1-Q12) FU-002117 (F1) FAN001082 (B1,B5) FAN001054 (B6,B7)
