Capacity Related Parameters B - 2
Drive Capacity Selection
Parameter o2-04 sets the Drive capacity according to the model number. Parameter o2-04 will need to be adjusted when replac-
ing a control board.
If a Control PCB is changed, the first time the Drive is powered up, parameter o2-04 must be set to the appropriate value listed
in Table B.1 for the Drive model number. After properly setting parameter 02-04, a 2-wire or 3-wire initialization must be per-
formed by setting parameter A1-03=2220 or A1-03=3330, respectively.This will automatically program the values of all other
parameters listed in Table B.2 to the factory settings for that particular Drive rating.
Table B.1 Drive Capacity Selection
Voltage Model Number o2-04 Setting Nominal Hp
208-240Vac
CIMR-P7U20P4 0
0.5/0.75
CIMR-P7U20P7 1
1
CIMR-P7U21P5 2
1.5/2
CIMR-P7U22P2 3
3
CIMR-P7U23P7 4
5
CIMR-P7U25P5 5
7.5
CIMR-P7U27P5 6
10
CIMR-P7U2011 7
15
CIMR-P7U2015 8
20
CIMR-P7U2018 9
25
CIMR-P7U2022 A
30
CIMR-P7U2030 B
40
208-230Vac
CIMR-P7U2037 C
50
CIMR-P7U2045 D
60
CIMR-P7U2055 E
75
CIMR-P7U2075 F
75/100
CIMR-P7U2090 10
125
CIMR-P7U2110 11
150
480Vac
CIMR-P7U40P4 20
0.5/0.75
CIMR-P7U40P7 21
1
CIMR-P7U41P5 22
1.5/2
CIMR-P7U42P2 23
3
CIMR-P7U43P7 24
5
CIMR-P7U45P5 26
7.5
CIMR-P7U47P5 27
10
CIMR-P7U4011 28
15/20
CIMR-P7U4015 29
25
CIMR-P7U4018 2A
30
CIMR-P7U4030 2C
40/50
CIMR-P7U4037 2D
60
CIMR-P7U4045 2E
75
CIMR-P7U4055 2F
100
CIMR-P7U4075 30
125
CIMR-P7U4090 31
150
CIMR-P7U4110 32
200
CIMR-P7U4160 34
250
CIMR-P7U4185 35
300/350
CIMR-P7U4220 36
400/450
CIMR-P7U4300 37
500+
.
