4 Operation
4.5.4 Digital Operator Displays during Testing without Motor
4-32
4.5.4 Digital Operator Displays during Testing without Motor
An asterisk (∗) is displayed before status display to indicate the test without a motor operation is in progress.
(Example: Status of power to the servomotor is OFF)
Note: The test without a motor status is not displayed during alarm occurs (A.).
Display Status
*RUN Power is supplied to the servomotor.
*BB Power to the servomotor is OFF.
*PT NT Forward or reverse run is prohibited.
*P-OT Forward run is prohibited.
*N-OT Reverse run is prohibited.
*HBB In hard-wire base block (safety) state.
∗ BB
− PRM/MON−
Un000=0 00000
Un002=0 00000
Un008=0 0000000000
Un00D=0 0000000000
To Next Page
