5.8 Additional Adjustment Function
5-63
5
Adjustments
5.8.3 Current Control Mode Selection Function
This function reduces high-frequency noises while the servomotor is being stopped. This function is enabled
by default and set to be effective under different application conditions. Set Pn009.1 = 1 to use this function.
This function can be used with the following SERVOPACKs.
5.8.4 Current Gain Level Setting
This function reduces noises by adjusting the parameter value for current control inside the SERVOPACK
according to the speed loop gain (Pn100). The noise level can be reduced by reducing the current gain level
(Pn13D) from its factory setting of 2000% (disabled). If the set value of Pn13D is decreased, the level of noise
will be lowered, but the response characteristics of the SERVOPACK will also be degraded. Adjust the current
gain level within the allowable range at which SERVOPACK response characteristics can be secured.
5.8.5 Speed Detection Method Selection
The speed detection method selection can be used to smooth the speed of the servomotor during operation. To
smooth the speed of the servomotor during operation, set Pn009 to n.1 to select speed detection 2.
Input Voltage SERVOPACK Model SGDV-
200 V 120A, 180A, 200A, 330A, 470A, 550A, 590A, 780A
400 V 3R5D, 5R4D, 8R4D, 120D, 170D, 210D, 260D, 280D, 370D
Parameter Meaning When Enabled Classification
Pn009
n. 0 Selects the current control mode 1.
After restart Tuning
n. 1
[Factory setting]
Selects the current control mode 2 (low noise).
• If current control mode 2 is selected, the load ratio may increase while the servomotor
is being stopped.
Pn13D
Current Gain Level
Classification
Setting Range Setting Unit Factory Setting When Enabled
100 to 2000 1% 2000 Immediately Tuning
• If this parameter is changed, the response characteristics of the speed loop will also
change, and the SERVOPACK may require readjustment.
Speed
Position
Parameter Meaning When Enabled Classification
Pn009
n. 0
[Factory setting]
Selects speed detection 1.
After restart Tuning
n. 1 Selects speed detection 2.
• If the speed detection method is changed, the response characteristics of the speed
loop will also change, and the SERVOPACK may require readjustment.
