YASKAWA SGMSV - List of Parameters

10 Appendix
10-2
10.1 List of Parameters
This section contains a tables of parameters.
Note: Do not change the following parameters from the factory settings.
• Reserved parameters
• Parameters not described in this manual
Parameter
No.
Size Name
Setting
Range
Units
Factory
Setting
When
Enabled
Classification
Reference
Section
Pn000
2 Basic Function Select Switch 0 0000 to 00B3 − 0000 After restart Setup −
Pn001
2
Application Function Select
Switch 1
0000 to 1122 − 0000 After restart Setup −
Direction Selection
Reference
Section
0 Sets CCW as forward direction.
4.3.1
1 Sets CW as forward direction. (Reverse Rotation Mode)
2 or 3 Reserved (Do not set.)
Reserved (Do not change.)
Reserved (Do not change.)
Reserved (Do not change.)
4th 3rd 2nd 1st
digit digit digit digit
n.

Servomotor power OFF or Alarm Gr.1 Stop Mode
Reference
Section
0 Stops the servomotor by applying DB (dynamic brake).
4.3.5
1 Stops the servomotor by applying DB and then releases DB.
2 Makes the servomotor coast to a stop state without using the DB.
Overtravel (OT) Stop Mode
Reference
Section
0 Stops in accordance with the setting of Pn001.0.
4.3.2
1 Sets the torque of Pn406 to the maximum value, decelerates the servomotor to a stop,
and then sets it to servolock state.
2 Sets the torque of Pn406 to the maximum value, decelerates the servomotor to a stop,
and then sets it to coasting state.
AC/DC Power Input Selection
Reference
Section
0 Applicable to AC power input: Input AC power supply through L1, L2, and L3
terminals.
3.1.4
1 Applicable to DC power input: Input DC power supply between B1/ + and −2, or input
DC power supply between B1/ + and −.
Reserved (Do not change.)
4th 3rd 2nd 1st
digit digit digit digit
n.

