6 Utility Functions (Fn)
6-24
6.14 Software Version Display (Fn012)
Select Fn012 to check the SERVOPACK and encoder software version numbers.
(1) Preparation
There are no tasks that must be performed before the execution.
(2) Operating Procedure
Use the following procedure.
Step Display after Operation Keys Operation
1
Press the Key to view the main menu for the
utility function.
Use the or Key to move through the list and
select Fn012.
2
Press the Key. The display changes to the Fn012
execution display.
The software versions of the SERVOPACK and the
connected encoder will appear.
Note:
If the servomotor is not connected, "Not connect" is
displayed.
3
Press the Key. The display returns to the main
menu of the utility function.
BB − FUNCTION−
Fn011:Motor Info
Fn012:Soft Ver
Fn013:MturnLmSet
Fn014:Opt Init
BB − Soft Ver−
DRIVER
Ver.=0001
ENCODER
Ver.=0003
BB − FUNCTION−
Fn011:Motor Info
Fn012:Soft Ver
Fn013:MturnLmSet
Fn014:Opt Init
