1.3 SERVOPACK Ratings and Specifications
1-3
1
Outline
1.3 SERVOPACK Ratings and Specifications
This section describes the ratings and specifications of SERVOPACKs.
1.3.1 Ratings
Ratings of SERVOPACKs are as shown below.
(1) SGDV with Single-phase, 100-V Rating
∗ Refer to 3.7 Connecting Regenerative Resistors for details.
(2) SGDV with Single-phase, 200-V Rating
∗1. The official model number is SGDV-120A11A008000.
∗2. Refer to 3.7 Connecting Regenerative Resistors for details.
(3) SGDV with Three-phase, 200-V Rating
∗ Refer to 3.7 Connecting Regenerative Resistors for details.
SGDV (Single Phase, 100 V) R70 R90 2R1 2R8
Continuous Output Current [Arms] 0.66 0.91 2.1 2.8
Instantaneous Max. Output Current [Arms] 2.1 2.9 6.5 9.3
Regenerative Resistor * None or external
Main Circuit Power Supply Single-phase, 100 to 115 VAC, +10% to -15%, 50/60 Hz
Control Power Supply Single-phase, 100 to 115 VAC, +10% to -15%, 50/60 Hz
Overvoltage Category III
SGDV (Single Phase, 200 V)
120
*1
Continuous Output Current [Arms] 11.6
Instantaneous Max. Output Current [Arms] 28
Regenerative Resistor
*2
Built-in or external
Main Circuit Power Supply Single-phase, 220 to 230 VAC, +10% to -15%, 50/60 Hz
Control Power Supply Single-phase, 220 to 230 VAC, +10% to -15%, 50/60 Hz
Overvoltage Category III
SGDV
(Three Phase, 200 V)
R70 R90 1R6 2R8 3R8 5R5 7R6 120 180 200 330 470 550 590 780
Continuous Output Current
[Arms]
0.66 0.91 1.6 2.8 3.8 5.5 7.6 11.6 18.5 19.6 32.9 46.9 54.7 58.6 78.0
Instantaneous Max. Output
Current [Arms]
2.1 2.9 5.8 9.3 11.0 16.9 17 28 42 56 84 110 130 140 170
Regenerative Resistor
*
None or external Built-in or external External
Main Circuit Power Supply Three-phase, 200 to 230 VAC, +10% to -15%, 50/60 Hz
Control Power Supply Single-phase, 200 to 230 VAC, +10% to -15%, 50/60 Hz
Overvoltage Category III
